SK8500
Product Features
Product Performance
*The above lifting parameters are the maximum test data in the factory, the actual lifting parameters are calibrated according to china national standard.
*The product images are for reference only. Due to the continuous improvement of technical design lifting parameters, other parameters and configurations are subject to change without notice.
| Performance Parameters | |
| Crane Model | SK8500.HK |
| Rated lifting moment (t.m) | 782.45 |
| Rated lifting capacity (Kg) | 230000 |
| Boom sections (/) | 5 |
| Max. boom length (m) | 18.00 |
| Max. lifting height (m) | 21.2 |
| Maximum elevation (°) | 75 |
| Slewing angle (°) | ∞ |
| Outrigger span (mm) | 5600 |
| Rated flow of system (L/min) | 130 |
| Operating pressure (Mpa) | 33 |
| Deadweight(Crane) (Kg) | 39760 |
| Deadweight(Truck & Crane) (Kg) | 54040±5% |
*The above lifting parameters are the maximum test data in the factory, the actual lifting parameters are calibrated according to china national standard.
*The product images are for reference only. Due to the continuous improvement of technical design lifting parameters, other parameters and configurations are subject to change without notice.
